Removal ProcedureInstallation Procedure

    Fig 1: View of Fuel Sender
    GM1376161Courtesy of GENERAL MOTORS CORP.
    CAUTION: Refer to Relieving Fuel Pressure Caution .
  1. Relieve the fuel system pressure. Refer to Fuel Pressure Relief .
    2. Fig 2: Removing And Installing Fuel Pump Access Cover
    GM1376163Courtesy of GENERAL MOTORS CORP.
    CAUTION: Refer to Battery Disconnect Caution .
  2. Disconnect the negative battery cable.
  3. Remove the rear seat. Refer to Rear Seat Cushion Replacement .
  4. Remove the fuel pump access cover.
    5. Fig 3: View of Fuel Tank Pressure Sensor Electrical Connector
    GM1376164Courtesy of GENERAL MOTORS CORP.
  5. Disconnect the electrical connector at the fuel pump assembly.
  6. Disconnect the fuel line.
  7. Remove the fuel pump assembly clip.
  8. Remove the fuel pump assembly from the tank.
  9. Remove and discard the gasket.
