Brake System Components
Brake System Components
Component Name
Callout
Brake Pressure Modulator Valve (BPMV)
1
Brake Fluid Level Switch
2
Electronic Brake Control Module (EBCM)
3
Steering Angle Sensor
4
Brake Pedal Position (BPP) Sensor
5
Yaw and Lateral Accelerometer Sensor
6
Park Brake Switch
7
Fig 1: Brake System Components
Courtesy of GENERAL MOTORS COMPANY
