Outside Rearview Mirror Remote Control and Multifunction Switch Replacement

Fig 1: Outside Rearview Mirror Remote Control & Multifunction Switch

Courtesy of GENERAL MOTORS COMPANY

Outside Rearview Mirror Remote Control and Multifunction Switch Replacement

Callout	Component Name
Preliminary Procedures  Remove the front side door trim. Refer to Front Side Door Trim Replacement .
1	Outside Rearview Mirror Remote Control and Multifunction Switch Screw (Qty: 4) CAUTION: Refer to Fastener Caution .
2	Outside Rearview Mirror Remote Control and Multifunction Switch Procedures  Disconnect electrical connector.
