Liftgate Release Switch Replacement

WARNING: This page is about a different car, the 2013 GMC Acadia, 2013 Chevrolet Traverse, and 2013 Buick Enclave. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Liftgate Release Switch
GM2675680Courtesy of GENERAL MOTORS COMPANY
Liftgate Release Switch Replacement

Callout Component Name
Preliminary Procedure
Remove the liftgate outside handle. Refer to Liftgate Outside Handle Replacement (Acadia, Traverse) .
1 Liftgate Release Switch
Procedure
Use a small flat-bladed tool on the 4 retainers, 2 on each side, to release the liftgate release switch.
