Front Side Door Window Switch Replacement

Fig 1: Front Side Door Window Switch
GM2219593Courtesy of GENERAL MOTORS COMPANY
Front Side Door Window Switch Replacement

Callout Component Name
Preliminary Procedure
Remove the door trim panel. Refer to Front Side Door Trim Panel Replacement .
1 Front Side Door Window Switch Assembly
TIP:  Use a flat bladed tool to release the switch from the trim panel.
