Left Front of Engine Components (LFX)
Left Front of Engine Components (LFX)
| Items |
|---|
| 1: G13 Generator G13 Generator X1G13 Generator X2 |
| 2: B52E Heated Oxygen Sensor - Bank 2 Sensor 1 (LFR or LFX) B52E Heated Oxygen Sensor - Bank 2 Sensor 1 |
| 3: T8B Ignition Coil 2 T8B Ignition Coil 2 (LFR/LFX) |
| 4: T8D Ignition Coil 4 T8D Ignition Coil 4 (LFR/LFX) |
| 5: T8F Ignition Coil 6 T8F Ignition Coil 6 |
| 6: G18 High Pressure Fuel Pump G18 High Pressure Fuel Pump (LFX) |
| 7: M64 Starter Motor M64 Starter Motor X1 (LFR/LFX)M64 Starter Motor X2M64 Starter Motor (LFX) |
| 8: B52F Heated Oxygen Sensor - Bank 2 Sensor 2 (LFR or LFX) B52F Heated Oxygen Sensor - Bank 2 Sensor 2 |
| 9: B68B Knock Sensor 2 B68B Knock Sensor 2 |
| 10: Q46 A/C Compressor Solenoid Valve Q46 A/C Compressor Solenoid Valve |
| 11: G1 A/C Compressor |
| 12: Q2 A/C Compressor Clutch Q2 A/C Compressor Clutch |
| 13: B37 Engine Oil Pressure Switch (LFR or LFX) B37 Engine Oil Pressure Switch (LFR/LFX) |
