Installation Procedure

  1. GM5925399Courtesy of GENERAL MOTORS COMPANY

    Liftgate Side Sensor (2) - Install

    2. CAUTION:

    Fastener Caution

  2. Rear End Spoiler Bolt (1) - Install and tighten - Fastener Specifications
  3. Connect the electrical connector.
  4. GM5920373Courtesy of GENERAL MOTORS COMPANY

    Liftgate Upper Side Trim Finish Panel (1) - Install

  5. GM5920285Courtesy of GENERAL MOTORS COMPANY

    Liftgate Upper Center Trim Finish Panel (1) - Install

  6. Close the liftgate.
