Rear Motor
Connect a jumper wire between Red terminal of center section and either Red-Green or Yellow-Green connection. Connect second jumper between Black terminal in center section and open in front section. If motor does not operate, reverse first jumper connections. If motor still does not operate, either harness or three-motor assembly should be replaced.
