Seat Temperature Control Module: Service and Repair

REMOVAL




1. Open hood, disconnect and isolate the negative battery cable remote terminal from the remote battery post.
2. Remove two module attaching screws.
3. Disconnect four module connectors.
4. Remove module from vehicle.

INSTALLATION
For installation reverse the above procedures.
