Support Brackets And Isolators: Installation

  1. Position isolator bracket to underbody and install attaching screws. See Figure . Tighten bracket screws to frame rail to 8.5 N.m (75 INCH lbs) and bracket screws to the rear panel to 3.7 N.m (33 INCH lbs).
  2. Connect isolator to exhaust system component.
