Torque Specifications
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | ||
|---|---|---|---|
| Axle Shaft Nut | 105 (142) | ||
| Brake Caliper-To-Steering Knuckle Bolts | 16 (22) | ||
| Hub & Bearing Assembly-To-Stub Shaft Nut | 105 (142) | ||
| Strut Assembly-To-Steering Knuckle Attaching Nuts | 155 (210) | ||
| Tie Rod End-To- Steering Knuckle Nut | 27 (37) | ||
| Wheel Lug Nuts | 100 (135) | ||
|
|||
