Courtesy Lamps Inoperative With Alarm Tripped

Test 1:






SYMPTOM
COURTESY LAMPS INOPERATIVE WITH ALARM TRIPPED

POSSIBLE CAUSES
- Courtesy lamps inoperative
- Body control module internal malfunction
