Engine Control Module: Description
WARNING: This page is about a different car, the 2006 Dodge Grand Caravan, 2006 Dodge Caravan, and 2006 Chrysler Town & Country. However, it is still accessible from the selected car via links, so may be relevant.
The ECM is located in the left front corner of the engine compartment attached to the radiator support. See Fig 1.
| 1 - BATTERY |
| 2 - IPM (INTEGRATED POWER MODULE) |
| 3 - ECM (ENGINE CONTROL MODULE) |
| 4 - RETAINING BOLT |
| 5 - RADIATOR SUPPORT |
| 6 - CLUTCH CABLE BRACKET (LHD) |
| 7 - CLUTCH CABLE BRACKET RETAINING BOLT (LHD) |
