First Time Calibration
A new Compass/Temp Mirror is shipped in a first time calibration mode. CAL is illuminated when the Compass/Temp Mirror is first powered up. The first time calibration mode can not be exited until the first time calibration process is completed. The CAL icon will remain illuminated to alert the driver that the Compass/Temp Mirror is operating in the CAL mode. Move the vehicle to an area away from large metallic objects or overhead power lines. While CAL is illuminated in the display the vehicle must be driven in 3 complete 360 degree circles at less than 5 MPH (8 KPH). The compass will calibrate; CAL will turn off, and then resume normal operation.
