Torque Specifications





Oil Pump to Block - Bolts 28 Nm (250 inch lbs.)
Oil Pump Cover - Bolts 12 Nm (105 inch lbs.)
Oil Pump Pick Up Tube - Bolt 28 Nm (250 inch lbs.)
