Battery Temperature Sensor: Removal

WARNING: This page is about a different car, the 2006 Dodge Viper. However, it is still accessible from the selected car via links, so may be relevant.

Make sure ignition switch is in the OFF position and all accessories are OFF.
Refer to BATTERY SYSTEM for removal of battery to access the battery temperature sensor. See Fig 1 and Fig 2

Fig 1: BATTERY HOLD DOWN
Courtesy of DAIMLERCHRYSLER CORP.
Disconnect electrical connector.
Remove Battery Temperature Sensor from battery tray.

Fig 2: BATTERY TEMPERATURE SENSOR

Courtesy of DAIMLERCHRYSLER CORP.
