Fog Light Switch Test

Remove fog light switch. See INSTRUMENT CLUSTER TRIM PANEL SWITCHES  under REMOVAL & INSTALLATION. Use ohmmeter to check switch circuit continuity. See Fig 1 . If continuity between related terminals is not as specified, replace switch.

Fig 1: Testing Instrument Cluster Trim Panel Switches
G92H04558Courtesy of CHRYSLER MOTORS.
