| Automatic Seat Belt Guide Rail Mounting Bolt (C) |
12-19 (17-26) |
| Automatic Seat Belt Buckle Mounting Bolt |
25-40 (35-55) |
| Automatic Seat Belt Guide Ring Attaching Bolt |
12-19 (17-26) |
| Front Seat Rail Mounting Bolt |
25-40 (35-55) |
| Front Seat Mounting Bolt |
25-40 (35-55) |
| Front Seat Mounting Nut |
17-26 (24-36) |
| Front Seat Slider Bracket Mounting Bolt |
25-40 (35-55) |
| Front Seat Frame Mounting Bolt (Inner) |
7-11 (10-15) |
| Front Seat Frame Mounting Bolt (Outer) |
25-40 (35-55) |
| Front Seat Adjuster Mounting Bolt |
7-10 (9-14) |
| Guide Ring Bracket Mounting Bolt |
7-10 (9-14) |
| Retractor Assembly (For Shoulder Belt) Mounting Bolt (Front) |
7-10 (9-14) |
| Retractor Assembly (For Shoulder Belt) Mounting Bolt (Rear) |
25-40 (35-55) |
| Retractor Assembly (For Lap Belt) Mounting Bolt (8x20mm) |
7-10 (9-14) |
| Retractor Assembly (For Lap Belt) Mounting Bolt |
25-40 (35-55) |
| INCH (N.m) |
| Automatic Seat Belt Motor Mounting Bolt |
35-53 (4-6) |
| Automatic Seat Belt Guide Rail Mounting Bolt (A), (B) |
35-53 (4-6) |
