Switch, Power Window: Installation: Installation

Fig 1: Power Window Switch Assembly

Courtesy of CHRYSLER GROUP, LLC

1. Position the switch (1) on the shifter bezel (3).
2. Install, and tighten the fasteners securing the switch.
3. Connect the electrical harness connectors (4) to the switches.
4. Position the bezel assembly; aligning the clips (2) with the console, and press into place.
5. Connect the negative battery cable.
