Module-Powertrain Control C3

Harness-Family: Ground_Jumper

Color: NA

Gender: FEMALE

Part Number: 15363919

Part Description: Not Available

Connector No: D3821G

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: Module-Powertrain Control C3 Connector End View
GCWD1084241Courtesy of CHRYSLER
Fig 2: Module-Powertrain Control C3 Component Location
GCWD1179113Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 Z900 BK 4 GROUND N/A
(1) Pins not listed are not used for this connector
