Compressor Manifold and Tube Assembly: Notes

Material

Item Specification
PAG Refrigerant Compressor Oil (R-134a Systems)
YN-12-D		 WSH-M1C231-B
Fig 1: Compressor Manifold And Tube Assembly With Torque Specifications
GF0040393Courtesy of FORD MOTOR CO.
Item Part Number Description
1 W50241-S441 Nut
2 9E889 O-ring
3 W50241-S441 Nut
4 9E889 O-ring
5 19D734 Manifold and tube assembly
