In-Vehicle Temperature and Humidity Sensor: Notes

Fig 1: Exploded View Of In-Vehicle Temperature & Humidity Sensor With Torque Specifications

Courtesy of FORD MOTOR CO.

Item	Part Number	Description
1	W707628	Steering column cover screw (3 required)
2	7804459	Steering column cover
3	W71087	Steering column reinforcement bolt (4 required)
4	78017A26	Steering column reinforcement
5	19D888	Aspirator hose
6	-	In-vehicle temperature and humidity sensor electrical connector (part of 14401)
7	19C734	In-vehicle temperature and humidity sensor
