Removal And Installation

  1. Remove the instrument panel center finish panel. Refer to INSTRUMENT PANEL FINISH PANEL - CENTER .
  2. Press the retaining tabs and remove the traction control switch.
    3. Fig 1: Removing/Installing Traction Control Switch
    G00378494Courtesy of FORD MOTOR CO.
  3. To install, reverse the removal procedure.
