Ignition Components LH Side
Fig 1: Heated Oxygen Sensor (HO2S) And Catalyst Monitor Sensor Replacement Components With Torque Specifications - RH
PART NUMBER REFERENCE
| Item | Part Number | Description |
|---|---|---|
| 1 | 14A464 | Ignition coil-on-plug electrical connector (4 required) (part of 12B637) |
| 2 | W706175 | Ignition coil-on-plug bolt (4 required) |
| 3 | 12A366 | Ignition coil-on-plug (4 required) |
| 4 | 12405 | Spark plug (4 required) |
- For additional information, refer to the appropriate procedures .
