Front Disc Brake (View 2 of 2)
WARNING: This page is about a different variant/trim than selected.
| Item | Part Number | Description |
|---|---|---|
| 1 | 386493 | Brake flexible hose retaining clip |
| 2 | 2C204 RH/ 2C205 LH | Wheel speed sensor |
| 3 | 2078 | Brake flexible hose |
| 4 | 388949 | Copper washers (2 required) |
| 5 | 385116 | Brake caliper flow bolt |
| 6 | - | Brake tube fitting (part of 2263 RH/2264 LH) |
- For additional information, refer to the appropriate procedures in this service information .
