Lamp-Ceiling 2-Rear

Component ID: 240
Component : LAMP-CEILING 2-REAR

Connector:
Name : LAMP-CEILING 2-REAR C1
Color : BLACK
# of pins : 1




Pin Circuit Description
1 U1036 18BR/DB GROUND



Connector:
Name : LAMP-CEILING 2-REAR C2
Color : BLACK
# of pins : 1




Pin Circuit Description
1 U41 18RD FUSED B(+)
