GMC
>>
1987
>>
Suburban 1/2 Ton 2WD V8-454 7.4L
>>
Repair and Diagnosis
>>
Locations
>>
Component Locations
>>
Modules
April 5, 2026:
LEMON Manuals is launched!
Read the announcement.
Modules
Firewall components & RH side of V8-454/7.4L:
RH Rear Of Engine Compartment
Applicable to: 4L engine. 1987 R & V series
