Engine Electrical Component Views

Fig 1: Identifying Engine Components - Top

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	Ignition Coil 3
2	Ignition Coil 5
3	Evaporative Emission (EVAP) Canister Purge Solenoid Valve
4	Throttle Body
5	Barometric Pressure (BARO) Sensor
6	Ignition Coil 6
7	Ignition Coil 4
8	Ignition Coil 2
9	Generator Inline Fuse
10	Intake Manifold Tuning (IMT) Solenoid Valve
11	Ignition Coil 1

Fig 2: View Of G114

Courtesy of GENERAL MOTORS CORP.

Fig 3: Identifying Camshaft Position (CMP) Actuators And Sensors

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	Camshaft Position (CMP) Actuator Solenoid - Intake Bank 1
2	Camshaft Position (CMP) Sensor - Intake Bank 1
3	Camshaft Position (CMP) Sensor - Intake Bank 2
4	Camshaft Position (CMP) Actuator Solenoid - Intake Bank 2
5	Camshaft Position (CMP) Actuator Solenoid - Exhaust Bank 2
6	Camshaft Position (CMP) Sensor - Exhaust Bank 2
7	Generator
8	A/C Compressor Clutch
9	Camshaft Position (CMP) Actuator Solenoid - Exhaust Bank 1
10	Camshaft Position (CMP) Sensor - Exhaust Bank 1

Fig 4: Identifying Components Near The Passenger Seat

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	Passenger Seat
2	Battery Current Sensor
3	Battery
4	G304
5	Inflatable Restraint Sensing and Diagnostic Module (SDM)
6	Inflatable Restraint Vehicle Rollover Sensor
7	YAW Rate and Lateral Acceleration Sensor
