Preliminary Procedure
- Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection .
- Reposition the engine control module bracket/battery hold-down retainer. Refer to Engine Control Module Replacement
.
- Remove the positive battery cable from the battery post. Refer to Battery Positive Cable Replacement (LFX) , Battery Positive Cable Replacement (LEA)
- Remove the push in retainers from the front portion of the left front bumper fascia opening cover and reposition the cover. Refer to Front Bumper Fascia Opening Cover Replacement (Equinox)
, Front Bumper Fascia Opening Cover Replacement (Terrain)
.
|
| 1 |
Battery Cover |
| 2 |
Engine Control Module Bracket Bolt
Tighten
9 N.m (80 lb in) |
| 3 |
Engine Control Module |
| 4 |
Battery Retainer Bracket Bolt
Tighten
9 N.m (80 lb in) |
| 5 |
Battery Retainer Bracket Nut
Tighten
9 N.m (80 lb in) |
| 6 |
Battery |
