J35A6 Engine

  1. Remove the battery.
  2. Remove the battery base (see step 12 in ENGINE REMOVAL  ).
  3. Disconnect the vacuum hose (A).
    Fig 1: Disconnecting Vacuum Hose (J35A6 Engine)
    G03703669Courtesy of AMERICAN HONDA MOTOR CO., INC.
  4. Remove the front engine mount stop (B), then remove the front engine mount (C).
  5. Install the front engine mount in the reverse order of removal.
