Rocker Arm Oil Control Valve Removal/Installation

  1. Remove the cowl cover and under-cowl panel (see COWL COVER REPLACEMENT ).
  2. Disconnect the rocker arm oil control valve connector (A) and the EOP sensor connector (B).
    Fig 1: Disconnecting Rocker Arm Oil Control Valve Connector And EOP Sensor Connector With Torque Specifications
    G00636071Courtesy of AMERICAN HONDA MOTOR CO., INC.
  3. Remove the rocker arm oil control valve (C).
  4. Install the parts in the reverse order of removal with a new rocker arm oil control valve filter (D).
