VSA Modulator-Control Unit Connector End View (View 266)

• BLK
• Left rear of engine compartment
• On left engine compartment wire harness

Fig 1: VSA Modulator-Control Unit Connector Terminal (View 266)

Courtesy of AMERICAN HONDA MOTOR CO., INC.
