Power Mirror Switch Test/Replacement

Remove the power window master switch panel (see POWER WINDOW MASTER SWITCH REPLACEMENT ).
Disconnect the 13P connector from the power mirror switch (A).

Fig 1: Identifying Power Mirror Switch
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Check for continuity between the terminals in each switch position according to the table.

Fig 2: Power Mirror Switch Connector Terminal Continuity Chart
Courtesy of AMERICAN HONDA MOTOR CO., INC.

*: There is continuity without operating a switch
If the continuity is not as specified, remove the screws and replace the power mirror switch.
