Cruise Control Combination Switch Test/Replacement

SRS components located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and precautions and procedures (see PRECAUTIONS AND PROCEDURES ), before doing repair or service.

1. Remove the driver's airbag (see DRIVER'S AIRBAG REPLACEMENT ).
2. Disconnect the cable reel sub harness 20P connector.
   Fig 1: Identifying Cable Reel Sub Harness 20P Connector

   Courtesy of AMERICAN HONDA MOTOR CO., INC.
3. Check for continuity between the terminals in each cruise control combination switch position according to the table:
   • If there is continuity, and it matches the table, but the cruise control combination switch failure occurred on the cruise control input test (see CRUISE CONTROL INPUT TEST  ), check and repair the wire harness on the switch circuit.
   • If there is no continuity in one or both positions, replace the cruise control combination switch (see STEERING WHEEL DISASSEMBLY/REASSEMBLY ).
     Fig 2: Cruise Control Combination Switch Continuity Chart

     Courtesy of AMERICAN HONDA MOTOR CO., INC.
4. Install the parts in the reverse order of removal.
