Cooling System Component Views
WARNING: This page is about a different car, the 2004 Hummer H2. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of GENERAL MOTORS CORP.
| Callout |
Component Name |
| 1 |
A/C Low Pressure Switch |
| 2 |
A/C Accumulator |
| 3 |
Intake Air Temperature (IAT)/Mass Air Flow (MAF) Sensor |
| 4 |
Coolant Level Switch (If Equipped) |
