Shift Lever: Assembly

WARNING: This page is about a different variant/trim than selected.
  1. Apply a coating of grease to the sliding part of the bushing.

    Specified grease:

    Chassis grease SAE J310, NLGI No. 2

    Fig 1: Applying Grease To Sliding Part Of Bushing
    G01171507Courtesy of HYUNDAI MOTOR CO.
  2. Apply the specified grease at the places shown in the figure.

    Specified grease:

    Multipurpose grease SAE J310, NLGI No. 2

    Fig 2: Locating Areas For Grease Application
    G01171508Courtesy of HYUNDAI MOTOR CO.
