4. Increase Mode

Fig 1: Solenoid Valve Operation During Increase Mode

Courtesy of HYUNDAI MOTOR CO.

If HECU determines there's no lock-up in the wheel, HECU cuts voltage to solenoid valve. So voltage is not supplied to each solenoid valve, brake fluid passes through the inlet valve to wheel cylinder, resulting in pressure increase.
