Repair Procedures: Installation

CAUTION:

Do not turn the ignition switch ON and do not contact the battery cable while replacing the front impact sensor.

Install the new front impact sensor.
Tighten the front impact sensor mounting nut.
Tightening torque:

7.8 ~ 9.8 N.m (0.8 ~ 1.0 kgf.m, 5.8 ~ 7.2 lb-ft)
Connect the front impact sensor connector.
Install the head lamp assembly (A). (Refer to the Body Electrical group - "Head lamps")
HEAD LAMP

Fig 1: Identifying Head Lamp Assembly
Courtesy of HYUNDAI MOTOR CO.
Reconnect the battery negative cable.
After installing the Front Impact Sensor, confirm proper system operation:
1. Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.
