Interior 2 Antenna

  1. Disconnect the negative (-) battery terminal.
  2. Remove the floor console assembly.

    (Refer to Body - "FLOOR CONSOLE ASSEMBLY ")

  3. Remove the rear bumper antenna (A) after loosening the mounting screws and disconnecting the connector (B).
    G13054243Courtesy of HYUNDAI MOTOR AMERICA
