Repair Procedures: Installation
NOTE:
- When installing the CVVD actuator, if the shaft gear does not fit properly, rotate the CVVD actuator in both directions and installing it naturally.
(Do not impact when installing the component.)
- Do not damage to the component when installing the cylinder head cover oil seal (A).
CAUTION:
- Install the component with the specified torques.
- Note that internal damage may occur when the component is dropped. If the component has been dropped, inspect before installing.
- Install in the reverse order of removal.
