Terminals And Reference Value For A/C And Av Switch

Fig 1: Displaying Terminal Reference Values For A/C & AV Switch (1 of 2)

Courtesy of NISSAN MOTOR CO., U.S.A.

Fig 2: Displaying Terminal Reference Values For A/C & AV Switch (2 of 2)

Courtesy of NISSAN MOTOR CO., U.S.A.
