Removal and Installation: Installation

CAUTION:

Perform additional service when replacing control module. Refer to Description .
When off-center is bigger than 120 deg., refer to Diagnosis Procedure to correct off-center before performing the work.

Note the following, and install in the reverse order of removal.

For installation, match mark (A) with mark (B).
Temporarily tighten bolts in sequence.
Torque to specification in reverse order.

Fig 1: Steering Angle Sub Control Module Tightening Sequence
Courtesy of NISSAN NORTH AMERICA, INC.

(Bolts)

: 6.4 N.m (0.65 kg-m, 57 in-Ib)
