Code 5 - Dump Valve Operates Excessively
Fig 1: Code 5 - System Operates Dump Valve Excessively (1 Of 2)
Courtesy of ISUZU MOTOR CO.
Fig 2: Code 5 - System Operates Dump Valve Excessively (2 Of 2)
Courtesy of ISUZU MOTOR CO.
Courtesy of ISUZU MOTOR CO.
Courtesy of ISUZU MOTOR CO.
