Removal & Installation

Disconnect negative battery terminal. Locate PCM. See Figure-Figure . If PCM is located under passenger's side floor, remove right door sill molding. Pull front passenger side carpet back to access PCM. Remove PCM cover screws. Disconnect PCM connectors. Remove mounting screws. Remove PCM. To install, reverse removal procedure. If PCM is located behind front kick panel, remove kick panel. Disconnect PCM connectors. Remove mounting screws. Remove PCM. To install, reverse removal procedure.
