Hands Free Shield Module Connector End View

MODULE-HANDS FREE SHIELD - 1 WAY

GCXH680459Courtesy of DAIMLERCHRYSLER CORP.
CAV CIRCUIT FUNCTION
1 X735 18GY/LB HANDS FREE MICROPHONE SHIELD
