Oil Intake Control Valve - Removal

REMOVAL





1. Remove intake manifold Intake Manifold - Removal.
2. Disconnect oil control valve electrical connector (2).
3. Remove oil control valve fastener (1).






NOTE: To remove the oil control valve, the engine must be at room temperature.

4. Rotate the oil control valve to break the seal. Pull the oil control valve out.
