Connector End Views & Electrical Component Locations: S310

Harness-Family: Body

Color: NA

Gender: FEMALE

Part Number: NA

Part Description: Not Available

Connector No: S130

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count:

Fig 1: S310 Connector End View
GCWD1006457Courtesy of CHRYSLER
Fig 2: S310 Component Location
GCWD1225306Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 X972 DG/WT 18 CAMERA SHIELD N/A
2 X972 NA 18 CAMERA SHIELD N/A
(1) Pins not listed are not used for this connector
