Fuse Array F1 70A (Standard) Connector End View (F0001U)

Harness-Family: PDC_Underhood

Color: NA

Gender: FEMALE

Part Number: Fuse-Midi-Mega

Part Description: Not Available

Connector No: F0001U

Option: Standard

Repair Kit Part Number: See StarParts

Cavity Count: 2

Fig 1: Fuse Array F1 70a Connector End View (Standard)
GCWD1079486Courtesy of CHRYSLER
Fig 2: Fuse Array F1 70a Component Location View (Standard)
GCWD1321914Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 A0 INTERNAL NA FUSED B(+) N/A
2 A951 INTERNAL NA FUSED B(+) N/A
