Torque Specifications

Torque Sequence:

Tightening Torque tensioner pulley lock bolt: 28-38 ft.lbs. (38-51 Nm)
Tightening Torque timing cover bolts: 70-96 in.lbs. (7.9-10.7 Nm)
Tightening Torque cylinder head cover bolts: 44-78 in.lbs. (5.0-8.8 Nm)
Tightening Torque crankshaft pulley lock bolt: 116-122 ft.lbs. (157-166 Nm)

Torque Sequence:

CAMSHAFT BEARING CAP BOLT TIGHTENING SEQUENCE
Torque: 100 - 125 inch lbs.(11.3 - 14.2 Nm, 1.15 - 1.45 kg-m)

CONNECTING ROD NUTS
Torque 34.7 - 36.9 ft. lbs. (47 - 50 Nm)
