| OFF |
Don't care |
Don't care |
OFF |
ON |
OFF |
| ON |
Don't care |
Don't care |
ON |
ON |
ON |
| DOOR |
OPEN |
OFF(*) |
ON during 20 min then directly OFF |
ON |
ON during 20 min |
| OPEN |
→LOCK(**) |
ON during 20 min then directly OFF |
ON |
ON during 20 min |
| OPEN |
→UNLOCK(***) |
ON during 20 min then directly OFF |
ON |
ON during 20 min |
| CLOSE |
OFF |
OFF |
ON |
OFF |
| CLOSE |
→ LOCK |
OFF |
ON |
OFF |
| CLOSE |
→UNLOCK |
ON during 30 min then directly OFF |
ON |
ON during 30 min |
| OPEN → CLOSE |
Don't care |
OFf (DECAY) |
ON |
OFf (DECAY) |
| CLOSE → OPEN |
Don't care |
ON during 20 min then directly OFF |
ON |
ON during 20 min |
| (*): OFF is transmitted when there is no action from Lock/Unlock. It has no impact on the 20mn timer (no restart). |
| (**): LOCK transition is sent by IPM only when door status is CLOSE. Thus there is no action on the 20mn timer in this case. |
| (***): When transition to UNLOCK is received, 20mn timer is restarted. |
